advanced forms

Tailwind CSS Advanced select

The Advanced Select Component enhances traditional select boxes with features like search and tagging, offering versatility for complex selection needs.

Require FlyonUI JS
Class Name
Type
Description
advance-select-toggleModifierThe advance-select-toggle component class is used for :toggleClasses, providing base styles to select toggle.
advance-select-menuModifierThe advance-select-menu component class is used for :dropdownClasses, providing base styles to select dropdown menu.
advance-select-optionModifierThe advance-select-option component class is used for :optionClasses, providing base styles for individual select dropdown options.
advance-select-tagModifierThe advance-select-tag component class is utilized for wrapperClasses when :mode is configured as tag.
select-activeStateapply active state to advance-select-option.
select-opened:{tw-utility-class}VariantThe modifier allows setting Tailwind classes when a select has been opened.
select-disabled:{tw-utility-class}VariantThe modifier allows setting Tailwind classes when a select has the disabled attribute.
selected:{tw-utility-class}VariantThe modifier allows setting Tailwind classes when a option is selected.
advance-select-xsSizeApply advance-select-xs along with advance-select-toggle to implement a extra small size.
advance-select-smSizeApply advance-select-sm along with advance-select-toggle to implement a small size.
advance-select-mdSizeApply advance-select-md along with advance-select-toggle to implement a medium(defautl) size.
advance-select-lgSizeApply advance-select-lg along with advance-select-toggle to implement a large size.
advance-select-xlSizeApply advance-select-xl along with advance-select-toggle to implement a extra large size.

Basic example

Default

A basic usage of advanced select.

Please refer to the Basic option section for all basic functionalities.

Placeholder

To customize the placeholder with either an icon or plain text, you can provide custom HTML within the "placeholder:" option as demonstrated below.

Size

Advanced select sizes

Add responsive class advance-select-{size} where {size} = xs|sm|md|lg|xl for advance select of different sizes. The size is now determined by the element’s height instead of its padding.

Validation states

Success state

Success state can be show using is-valid class.

Error state

Error state can be show using is-invalid class.

Illustrations

Fixed position

To fix the dropdown’s vertical placement, you can specify the dropdownVerticalFixedPlacement: option and define the desired position, as demonstrated in the example below.

Disabled

To render selects as inactive, include the disabled boolean attribute within the select element and utilize the class select-disabled:* within the "toggleClasses": section for styling purposes.

Multiple

Select multiple options.

Please refer to the Multiple option section for all multiple related functionalities.

Multiple with option template

Select multiple options and add an option template.

Multiple with counter

If you only want to display the number of the selected option in multiple select. then use "toggleCountText":.

Multiple with conditional counter

Use multiple tag to enable counter option that counts the number of selected options.

Search

To enable searching within the dropdown, set "hasSearch": true.

Please refer to the Search option section for all search-related functionalities.

Search result limit

Set a maximum limit for search results by using the parameter searchLimit: 5.

Minimum search Length

new

Set "minSearchLength":2 to define the minimum number of characters required before initiating a search.

Direct match searching Off

Set isSearchDirectMatch: false to turn off direct match searching, allowing for broader search results without exact term matching.

Tags

Create a custom select with removable tags using the provided options:

  • "wrapperClasses": This option wraps the select element. Apply the class advance-select-tag for default styling.
  • "tagsItemTemplate": This section is dedicated to styling the selected tag.
  • Use data-select-option to customize options.

Please see the Tags option section for tag-related functionalities.

Sizing advance-select-* doesn’t work for tags options

Custom option

Example of custom option with avatar and icons. Using data-select-option for providing content for the option.

Icon

Basic example of options with icon.

Avatar

Basic example of options with avatar.

Modal example

Basic usage in modal window.

Add/Remove option

Utilize the addOption and removeOption methods to add or remove options, respectively.

Destroy/Reinitialize

The destroy method is provided to facilitate the destruction of a select element.

Set a single value with a setter.

Provides setValue method that helps to set a value programmatically.

Set a multiple value with a setter.

Provides setValue method that helps to set a value programmatically.

Remote data selection

Set apiUrl: "https://some-path.com/api" to configure selection based on remote data, allowing data to be fetched dynamically from the specified API endpoint.

Remote data selection (multiple options)

Allow multiple options to be selected by setting apiUrl: "https://some-path.com/api", enabling dynamic selection from remote data provided by the specified API endpoint.

Remote data selection with removable tags

Enable selection with removable tags using apiUrl: "https://some-path.com/api", allowing choices to be dynamically loaded from remote data and displayed as tags.

Multiple selection with option template (remote data)

Enable multiple option selection with a custom template by setting apiUrl: "https://some-path.com/api". This allows selections to be dynamically built from remote data with a specified option format.

Multiple with conditional counter (remote data)

Use multiple tag to enable counter option that counts the number of selected options. Use apiUrl: "https://some-path.com/api" to enable build select according to the remote data.

Custom template with avatars (remote data)

Create a custom selection design featuring avatars by setting apiUrl: "https://some-path.com/api". This enables options to be dynamically loaded from remote data and displayed with personalized avatar styling..

Modal example with overflow:hidden

Use dropdownScope: "window" to display a select dropdown inside a parent element with hidden overflow, ensuring the dropdown remains visible and accessible within the window scope.

When dropdownScope is set to window, the dropdownClasses include w-full (required to update updateDropdownWidth()) and z-80 (necessary to ensure the dropdown displays above the backdrop).

JavaScript behavior

Options

PARAMETERS
DESCRIPTION
OPTIONS
DEFAULT VALUE
Basic Options
data-selectUsed to create a custom select options.--
data-select-optionUsed to add a custom option with a description and an icon.--
:placeholderDefine a default placeholder when nothing is selected.stringSelect...
:toggleClassesDefine CSS classes for the selects’ toggle (styles the button). CSS classes must be separated by a space.string-
:toggleTagDefine the markup structure for the select toggle.Note: data-title is required if you are using a custom placeholder.One line HTML markup—
:dropdownClassesDefine CSS classes for the dropdown menu. CSS classes must be separated by a space.string-
:dropdownPlacementSpecifies the position of the menu when opened.top, top-start, top-end, bottom, bottom-start, bottom-end, right, right-start, right-end, left, left-start, left-endbottom
:dropdownVerticalFixedPlacementSpecifies a fixed vertical position for the menu when opened. It will not change when scrolling."top" / "bottom" / nullnull
:dropdownScopeDetermines whether the dropdown will be moved outside the parent, for correct display in elements with hidden overflow. Requires the Popper plugin.window, parentparent
:optionClassesStyling is applied to individual options, so use Tailwind CSS classes to style the options.string-
:optionTemplateDefine template for the single option. It could contain:
  • data-icon attribute: If the target option tag contains data-select-option:icon, the specified image will be placed within the tag with this attribute.
  • data-title attribute: The text from the target option will be inserted inside the tag with this attribute.
  • data-description attribute: If the target option tag contains data-select-option:description, the specified text will be placed inside the tag with this attribute.
One line HTML markup-
:extraMarkupProvide markup that can be added to the select wrapper for decorative purposes.One line HTML markup or Array of one line HTML markup-
:isOpenedIf the value is true, the select is opened.booleanfalse
:dropdownSpaceYou have the ability to adjust the spacing between the select element and its menu.number10
:optionTagDefine the markup for the wrapper tag of a single option.
Do not update. This HTML markup must remain as is. Changing it could potentially cause issues.		One line HTML markup<div></div>
:descriptionClassesSpecify CSS classes for the description within each individual option. Ensure that the classes are separated by a space.string-
:iconClassesSpecify CSS classes for the icons within each individual option. Ensure that the classes are separated by a space.string-
Multiple Options
:toggleCountTextThis feature is exclusive to multiple select. It defines the text to appear after the counter and activates the counting mode.string-
:toggleCountTextPlacementAllows to specify where the text specified in the toggleCountText parameter will be located relative to the counter.'postfix' / 'prefix' / 'postfix-no-space' / 'prefix-no-space'postfix
:toggleCountTextMinItemsThis feature is specific to multiple selects. It sets the minimum number of selected items required to activate the counting mode.number1
:toggleSeparatorsDefine separators for the toggle options in the selects.object-
:toggleSeparators:itemsDefine which separator will be used for separate selected items.string`,
:toggleSeparators:betweenItemsAndCounterDefine which separator will be used for separate selected items and counter text.stringand
:toggleCountTextModeThis option is only available for multiple select. controls the display of the contents of the button title.‘countAfterLimit’ or ’nItemsAndCount’countAfterLimit
Search Options
:hasSearchIf the value is true, include a search field within the dropdown.booleanfalse
:preventSearchFocusIf the value is true, disable autofocus for the search field within the dropdown list.booleanfalse
:searchWrapperTemplateDefine the markup for the wrapper tag for the search.
Do not update. This HTML markup must remain as is. Changing it could potentially cause issues.		One line HTML markup<div></div>
:searchWrapperClassesProvide the option to style the search wrapper using Tailwind classes. Make sure the classes are separated by spaces.stringbg-base-100 sticky top-0 mb-2 px-2 pt-3
:searchIdThis option is only available when hasSearch: true. This option is useful if there is a need to associate a label outside the initialized element with the search input.string-
:searchClassesApply Tailwind CSS classes to style the search bar. Ensure that the classes are separated by a space.stringborder-base-content/40 focus:border-primary focus:outline-primary bg-base-100 block w-full rounded-field border px-3 py-2 text-base focus:outline-1
:searchPlaceholderThis option is applicable only when the :hasSearch attribute is set to true. It specifies the placeholder text for the search field within the dropdown.stringSearch...
:searchNoResultTextSpecifies the text to be shown when no results are found.stringNo options found...
:searchNoResultClassesSpecify CSS classes for the wrapper surrounding the “no results” message. Ensure that the classes are separated by a space.stringblock advance-select-option
advance-select-option class is a custom class. Refer to the class table for more details.
:optionAllowEmptyOptionThis option allows the inclusion of an empty option in the list. When enabled (true), an additional option with an empty string ("") as its value will be displayed, providing users the ability to select a blank choice if necessary.booleanfalse
:searchLimitThis option is only available when hasSearch: true. If this option is enabled, the search will display only the first ’n’ matching items.numberinfinity
:minSearchLengthSets the minimum number of characters required to activate the search functionality.number0
:isSearchDirectMatchThis option is only available when hasSearch: true. If the option is disabled, then in the search results you will be able to see non-direct matches by text. For example, if you entered england in the search field, then Eng-land, Eng.land, Eng_land will also be shown.booleantrue
:searchNoResultTemplateThis option is only available when :hasSearch attribute is true. Define a markup for the “no result” text.string<span></span>
Tags Options
:modeDefine a select mode.default or tagsdefault
:dropdownTagSpecify the markup for the dropdown accordingly.
Do not update. This HTML markup must remain as is. Changing it could potentially cause issues.		One line HTML markup<div></div>
:wrapperClassesDefine CSS classes for the wrapper of the select elements. These classes are applied to the main wrapper. Ensure that the classes are separated by spaces.string-
:tagsItemTemplateDefine template for the single option. It could contain:
  • data-icon attribute: If the target option tag contains data-select-option:icon, the specified image will be placed within the tag with this attribute.
  • data-title attribute: The text from the target option will be inserted inside the tag with this attribute.
  • data-description attribute: If the target option tag contains data-select-option:description, the specified text will be placed inside the tag with this attribute.
One line HTML markup-
:tagsItemClassesApply styling to the select tag wrapper. Ensure that the classes are separated by spaces.string-
:tagsInputIdThis option is only available when tags mode is set up. This option is useful if there is a need to associate a label outside the initialized element with the tags input.string-
:tagsInputClassesThis work as input for search. Specify CSS classes for the input field within the dropdown list. Ensure that the classes are separated by spaces.string-
:isAddTagOnEnterWhen you search and press Enter, it creates an entry within the options. This setting determines whether a tag will be added when the Enter key is pressed.booleantrue
Remote Data Options
:apiUrlDefines the address where the API is located.string, nullnull
:apiQueryDefines query parameters that are separated by ?.string, nullnull
:apiOptionsDefines options for the fetch function.RequestInit , nullnull
:apiDataPartIf data is in some first level parameter, then it allows you to specify the name of this parameter to extract the data.string , nullnull
:apiSearchQueryKeyDefines the key for the query search parameter.string , nullnull
:apiFieldsMapAllows you to convert fields from the API to the fields required for the plugin to work.{ id: string; title: string; icon?: string, null; description?: string, null} , nullnull
:apiIconTagAllows to define an img tag that will be used when rendering options and in the trigger button.string , nullnull

Methods

The HSSelect object is contained within the global window object.

METHOD
DESCRIPTION
PUBLIC METHODS
destroy()Destroys select.
open()Open dropdown list.
close()Close dropdown list.
setValue()Set the select value: use a string for a single select and an array for a multiple select.
addOption(items)Include an option, or potentially multiple options, to the select menu. Each individual option should adhere to this interface.
{ title: string; val: string; options?: { description: string; icon: string; }; }
removeOption(val)Remove an option by its value (multiple options possible).
recalculateDirection()Trigger a recalculation for the dropdown list.
STATIC METHODS
HSSelect.getInstance(target, isInstance)
Returns the element linked to the target.
  • target should be a Node or string (valid selector).
  • isInstance boolean. Returns the instance instead of Node if true.
HSSelect.close(target).
Close the element linked to the target.
  • target should be a Node or string (valid selector).
HSSelect.closeCurrentlyOpened(evtTarget)
Close the element linked to the target.
  • target should be a Node.

Method usage

Below is a demonstration of how to use the methods. Assign an ID to the data-select element. To test other methods, copy the following code into your console and click the button.

Open item (public method).

<select id="select" class="--prevent-on-load-init" data-select>
...
</select>

// This method is used in above example.
const select = new HSSelect(document.querySelector('#method-select'));
const openBtn = document.querySelector('#open-btn');

openBtn.addEventListener('click', () => {
  select.open();
});

Open item (static method).

const openBtn = document.querySelector('#open-btn');

openBtn.addEventListener('click', () => {
  HSSelect.open('#select');
});

Open item (mixed).

const { element } = HSSelect.getInstance('#method-select', true);
const openBtn = document.querySelector('#open-btn');

openBtn.addEventListener('click', () => {
  element.open();
});

Set value method

Set value.

const select = HSSelect.getInstance('#select');
const setValueBtn = document.querySelector('#set-value-btn');

setValueBtn.addEventListener('click', () => {
  select.setValue('address');
  // if select is multiple
  // select.setValue(['address', 'email']);
});

Add & Remove options

Add options (public method).

const select = window.HSSelect.getInstance('#add-remove-select');
const addOptionsBtn = document.querySelector('#add-option');

addOptionsBtn.addEventListener('click', () => {
  select.addOption([
    {
      title: "James Collins",
      val: "1",
    },
    {
      title: "Amanda Harvey",
      val: "2",
    }
  ]);
});

Remove options (public method).

const select = window.HSSelect.getInstance('#add-remove-select');
const removeOptionsBtn = document.querySelector('#remove-option');
removeOptionsBtn.addEventListener('click', () => {
  select.removeOption(["1", "2"]);
});

Destroy instance

Destroy instance (public method).

const destroyBtn = document.querySelector('#destroy-btn');
const select = window.HSSelect.getInstance('#destroy-select');
destroyBtn.addEventListener('click', () => {
  select.destroy();
});

Events

METHOD
DESCRIPTION
RETURNING VALUE
on:changeCalled when any select is changed.Current value

Event usage

Display a console log message when an option is selected.

When select changes event example.

const el = HSSelect.getInstance(document.getElementById('event-select'));

el.on('change', (instance) => {console.log("selected")});
